| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
H11A5MTRANSISTOR OUTPUT OPTOCOUPLER |
2,980 | $0.22 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 5000Vrms | 30% @ 10mA | - | 3µs, 3µs | - | DC | Transistor with Base | 80V | - | 1.2V | 60 mA | 400mV | -55°C ~ 110°C | Through Hole |
|
CNY17F13SDTRANSISTOR OUTPUT OPTOCOUPLER |
2,358 | $0.22 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 5300Vrms | 40% @ 10mA | 80% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor | 70V | 50mA | 1.35V | 100 mA | 300mV | -55°C ~ 100°C | Surface Mount |
|
|
H11A3MTRANSISTOR OUTPUT OPTOCOUPLER |
2,853 | $0.22 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 5000Vrms | 20% @ 10mA | - | 3µs, 3µs | - | DC | Transistor with Base | 80V | - | 1.2V | 60 mA | 400mV | -55°C ~ 110°C | Through Hole |
|
|
TIL189-1DARLINGTON OUTPUT OPTOCOUPLER |
3,191 | $0.22 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
TIL917CDARLINGTON OUTPUT OPTOCOUPLER |
3,394 | $0.23 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
TIL923DARLINGTON OUTPUT OPTOCOUPLER |
3,397 | $0.23 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MOC8103SDTRANSISTOR OUTPUT OPTOCOUPLER |
2,804 | $0.23 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 5300Vrms | 108% @ 10mA | 173% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor | 30V | 50mA | 1.15V | 100 mA | 400mV | -55°C ~ 100°C | Surface Mount |
|
MOC213VMTRANSISTOR OUTPUT OPTOCOUPLER, 2 |
3,828 | $0.23 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 2500Vrms | 100% @ 10mA | - | 7.5µs, 5.7µs | 3.2µs, 4.7µs | DC | Transistor with Base | 30V | 150mA | 1.15V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
MOC211VMOPTOISO 2500VRMS 1CH TRANS 8SOIC |
2,728 | $0.23 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 2500Vrms | 20% @ 10mA | - | 7.5µs, 5.7µs | 3.2µs, 4.7µs | DC | Transistor with Base | 30V | 150mA | 1.15V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
MOC213R2VMTRANSISTOR OUTPUT OPTOCOUPLER |
2,157 | $0.23 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 2500Vrms | 100% @ 10mA | - | 7.5µs, 5.7µs | 3.2µs, 4.7µs | DC | Transistor with Base | 30V | 150mA | 1.15V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
MOC216TRANSISTOR OUTPUT OPTOCOUPLER |
2,599 | $0.23 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 2500Vrms | - | - | 7.5µs, 5.7µs | 3.2µs, 4.7µs | DC | Transistor with Base | 30V | 150mA | 1.07V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
|
TIL917BDARLINGTON OUTPUT OPTOCOUPLER |
2,525 | $0.23 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MOC8100SR2MTRANSISTOR OUTPUT OPTOCOUPLER |
2,826 | $0.24 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 7500Vpk | 30% @ 1mA | - | 20µs, 20µs (Max) | 2µs, 2µs | DC | Transistor with Base | 30V | - | 1.2V | 60 mA | 500mV | -55°C ~ 100°C | Surface Mount |
|
|
TIL118-2TRANSISTOR OUTPUT OPTOCOUPLER |
2,559 | $0.24 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
ACPL-227-50BEOPTOISOLATOR 3KV 2CH TRANS 8-SO |
3,769 | $1.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 | 3000Vrms | 130% @ 5mA | 260% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 400mV | -55°C ~ 110°C | Surface Mount |
|
TLP290-4(TP,EOPTOISOLTR 2.5KV 4CH TRANS 16-SO |
2,102 | $1.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 4 | 2500Vrms | 50% @ 5mA | 400% @ 5mA | 3µs, 3µs | 2µs, 3µs | AC, DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 400mV | -55°C ~ 110°C | Surface Mount |
.JPG)
|
TLP2309(TPL,E)OPTOISO 3.75KV TRANS 6-SO 5 LEAD |
3,010 | $1.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 3750Vrms | 15% @ 16mA | - | 1µs, 1µs (Max) | - | DC | Transistor | 20V | 8mA | 1.55V | 25 mA | - | -40°C ~ 110°C | Surface Mount |
|
|
TLP293-4(GB-TP,EOPTOISOLATOR 3.75KV TRANS SO16 |
3,223 | $1.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 4 | 3750Vrms | 100% @ 5mA | 600% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 125°C | Surface Mount |
|
|
TLP293-4(LGBTP,EOPTOISOLATOR 3.75KV TRANS SO16 |
3,808 | $1.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 4 | 3750Vrms | 100% @ 500µA | 600% @ 500µA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 125°C | Surface Mount |
|
|
MOC211R2VMOPTOISO 2500VRMS 1CH TRANS 8SOIC |
2,313 | $0.24 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 2500Vrms | 20% @ 10mA | - | 7.5µs, 5.7µs | 3.2µs, 4.7µs | DC | Transistor with Base | 30V | 150mA | 1.15V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
