| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
;;.jpg)
|
224CMQ040DIODE SCHOTTKY 40V 110A PRM4 |
2,733 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 40 V | 110A | 520 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 40 V | -55°C ~ 125°C | Chassis Mount |
|
|
224CMQ045DIODE SCHOTTKY 45V 110A PRM4 |
2,267 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 45 V | 110A | 520 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 45 V | -55°C ~ 125°C | Chassis Mount |
;;.jpg)
|
224CNQ035DIODE SCHOTTKY 35V 110A PRM4 |
3,135 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 35 V | 110A | 520 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 35 V | -55°C ~ 125°C | Chassis Mount |
|
|
224CNQ040DIODE SCHOTTKY 40V 110A PRM4 |
2,877 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 40 V | 110A | 520 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 40 V | -55°C ~ 125°C | Chassis Mount |
|
|
224CNQ045DIODE SCHOTTKY 45V 110A PRM4 |
2,977 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 45 V | 110A | 520 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 45 V | -55°C ~ 125°C | Chassis Mount |
|
|
225CMQ015DIODE SCHOTTKY 15V 110A PRM4 |
2,257 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 15 V | 110A | 380 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 40 mA @ 15 V | -55°C ~ 125°C | Chassis Mount |
|
|
225CNQ015DIODE SCHOTTKY 15V 110A PRM4 |
2,353 | $54.91 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 15 V | 110A | 380 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 40 mA @ 15 V | -55°C ~ 125°C | Chassis Mount |
|
PR250KN8NDIODE MODULE ANODE COMMON D+D 80 |
2,995 | $55.04 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Anode | Standard | 800 V | 250A | 1.33 V @ 800 A | Standard Recovery >500ns, > 200mA (Io) | - | 30 mA @ 800 V | -40°C ~ 150°C | Chassis Mount |
|
|
VS-VSUD400CW20DIODE GEN PURP 200V 330A TO244 |
3,917 | $55.13 |
RFQ |
Bulk | FRED Pt® | Active | 1 Pair Common Cathode | Standard | 200 V | 330A | 2 V @ 200 A | Standard Recovery >500ns, > 200mA (Io) | 90 ns | 1.38 mA @ 200 V | -40°C ~ 150°C | Chassis Mount | |
|
|
VS-409CNQ135PBFDIODE MODULE 135V 400A TO244AB |
2,597 | $55.16 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 135 V | 400A | 1.46 V @ 400 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 6 mA @ 135 V | - | Chassis Mount |
|
|
MDD142-14N1DIODE MODULE 1.4KV 165A Y4-M6 |
3,237 | $55.39 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Series Connection | Standard | 1400 V | 165A | 1.3 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 20 mA @ 1400 V | - | Chassis Mount |
|
|
MDD142-18N1DIODE MODULE 1.8KV 165A Y4-M6 |
2,391 | $55.70 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Series Connection | Standard | 1800 V | 165A | 1.3 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 20 mA @ 1800 V | - | Chassis Mount |
|
|
VS-HFA280NJ60CPBFDIODE STANDARD 600V 280A TO244 |
2,245 | $55.75 |
RFQ |
Datasheet |
Tray | HEXFRED® | Active | 1 Pair Common Cathode | Standard | 600 V | 280A | 2.1 V @ 210 A | Fast Recovery =< 500ns, > 200mA (Io) | 39 ns | 8 µA @ 600 V | -55°C ~ 150°C | Chassis Mount |
|
VS-HFA70EA120DIODE MODULE 1.2KV 35A SOT227 |
2,052 | $55.96 |
RFQ |
Datasheet |
Bulk | HEXFRED® | Active | 2 Independent | Standard | 1200 V | 35A (DC) | 3 V @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | 145 ns | 75 µA @ 1200 V | - | Chassis Mount |
|
MDD172-12N1DIODE MODULE 1.2KV 190A Y4-M6 |
3,525 | $55.98 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Series Connection | Standard | 1200 V | 190A | 1.15 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 20 mA @ 1200 V | - | Chassis Mount |
|
M5060CC400DIODE GEN PURP 400V 60A MODULE |
3,400 | $61.18 |
RFQ |
Datasheet |
Bulk,Box | - | Active | 1 Pair Common Cathode | Standard | 400 V | 60A | 1.35 V @ 50 A | Standard Recovery >500ns, > 200mA (Io) | - | - | -40°C ~ 125°C | Chassis Mount |
|
286-809CM-D LIGHT GRAY |
3,469 | $57.14 |
RFQ |
Datasheet |
Box | - | Active | 1 Pair Common Anode | Standard | 1000 V | 1A | - | Standard Recovery >500ns, > 200mA (Io) | - | - | -25°C ~ 40°C | Socketable |
|
|
VS-401CNQ040PBFDIODE ARRAY SCHOTTKY 40V TO244 |
2,769 | $57.27 |
RFQ |
Datasheet |
Tray | - | Active | 1 Pair Common Cathode | Schottky | 40 V | 40A | 590 mV @ 40 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4 mA @ 40 V | 150°C (Max) | Chassis Mount |
|
MSRT100100ADDIODE GEN 1KV 100A 3 TOWER |
3,437 | $57.70 |
RFQ |
Bulk | - | Active | 1 Pair Series Connection | Standard | 1000 V | 100A | 1.1 V @ 100 A | Standard Recovery >500ns, > 200mA (Io) | - | 10 µA @ 1000 V | -55°C ~ 150°C | Chassis Mount | |
|
|
MSRT100120ADDIODE GEN 1.2KV 100A 3 TOWER |
2,881 | $57.70 |
RFQ |
Bulk | - | Active | 1 Pair Series Connection | Standard | 1200 V | 100A | 1.1 V @ 100 A | Standard Recovery >500ns, > 200mA (Io) | - | 10 µA @ 1200 V | -55°C ~ 150°C | Chassis Mount |
